26 in City Commuter E-Bike
HKM-4196563 City Electric Bike
The HKM-4196563 is a 26 in city commuter with a 250 W brushless rear hub motor and a 36 V 15 Ah pack (about 540 Wh) good for up to 120 km per charge. Balloon tires, a front suspension fork, and a Shimano 7-speed drivetrain keep the ride smooth and simple, with mechanical disc brakes and CE-certified electronics.
250 W Brushless Motor36 V 15 Ah / 540 WhUp to 75 mi Range26 x 2.35 in TiresShimano 7-SpeedFront SuspensionMechanical Disc BrakesCE Certified
Motor
250 W
Brushless rear hub
Battery
36 V 15 Ah
About 540 Wh lithium-ion
Top Speed
15.5 mph
25 km/h, assist dependent
Range
Up to 75 mi
120 km per charge
Tires
26 x 2.35 in
Balloon-profile tires
Load Capacity
265 lb
120 kg rider plus cargo
Overview
A city bike should disappear into the commute, and the HKM-4196563 is built to do exactly that. A 250 W brushless rear hub motor gives smooth, quiet help up to 15.5 mph (25 km/h), and a 36 V 15 Ah pack stores about 540 Wh for up to 120 km of assisted riding - enough for a week of short trips between charges.
The 26 in balloon tires soak up small chatter while a front suspension fork handles the sharper hits, and mechanical disc brakes keep stopping consistent in wet weather. A Shimano 7-speed drivetrain lets you keep the motor in its efficient band, which directly protects range.
Three riding modes - assist, ride, and pure electric - let you choose how much the motor helps, and the LCD shows speed, battery, and distance at a glance. The electronics are CE certified, and the bike suits riders from 165 to 190 cm tall.
Key Features
250 W Brushless Rear Hub Motor
A sealed brushless DC motor gives smooth, quiet assist up to 15.5 mph (25 km/h) with no carbon brushes to wear. Output is tuned for composed city riding and gentle climbs rather than outright speed.
36 V 15 Ah Lithium Pack (About 540 Wh)
An intelligent battery management system monitors cell voltage, temperature, and balance, and protects against overcharge, over-discharge, short circuit, and thermal runaway. The pack recharges in 7-8 hours.
Front Suspension Fork
A front suspension fork absorbs the square-edged hits at the front wheel while the balloon tires damp everything smaller. The combination delivers most of the comfort of a full-suspension frame without the extra weight.
Mechanical Disc Brakes
Mechanical disc brakes keep the friction surface clear of tire spray, so stopping stays consistent in rain and dust. Cable actuation is simple to adjust with basic tools and cheap to maintain.
Shimano 7-Speed Drivetrain
A Shimano 7-speed system gives crisp, precise shifts for climbs, flats, and descents. Keeping the right cadence also keeps the motor in its efficient band, which directly protects range.
26 x 2.35 in Balloon Tires
The balloon-profile tires spread rider and bike weight across a generous contact patch for a stable, cushioned ride, and the air volume works as natural suspension over small bumps.
LED Lighting Front and Rear
LED lights draw from the main pack, so there are no separate cells to keep charged before an early start or a ride home in the dark. The rear light keeps you visible to traffic.
Lightweight, Anti-Oxidation Frame
A lightweight frame with anti-oxidation treatment resists corrosion season after season, and balanced geometry keeps the bike stable at speed and nimble at walking pace.
Full Specifications
Model
HKM-4196563 | City Electric Bike
Frame Material
Lightweight, anti-oxidation frame
Motor
250 W brushless rear hub motor
System Voltage
36 V DC
Battery
36 V 15 Ah lithium-ion (about 540 Wh) with BMS
Charger
Supplied smart charger
Charging Time
7-8 hours from empty
Battery Protection
BMS guards overcharge, over-discharge, short circuit, thermal
Top Speed
15.5 mph (25 km/h), assist dependent
Range Per Charge
Up to 75 mi (120 km), assist dependent
Climbing
Up to 25 degrees; assisted climbs
Motor Efficiency
Brushless commutation, low heat
Drivetrain
Shimano 7-speed
Brakes
Mechanical disc brakes, front and external
Suspension
Front suspension fork
Tires
26 x 2.35 in balloon tires
Wheels
26 in rims with reinforced spokes
Saddle
Padded saddle, upright riding position
Display
LCD display: speed, battery, distance
Assist System
3 modes: assist, ride, pure electric
Lighting
LED front and rear lights
Load Capacity
265 lb (120 kg) rider plus cargo
Bike Weight
About 55 lb (24.8 kg) including battery
Rider Height
165-190 cm (5 ft 5 in - 6 ft 3 in)
Warranty
24 Months Warranty Service (parts and labor)
Battery, Range, and Charging
The 36 V 15 Ah pack stores about 540 Wh and is protected by an intelligent battery management system that monitors cell voltage, temperature, and balance, guarding against overcharge, over-discharge, short circuit, and thermal runaway.
Quoted range is up to 75 mi (120 km) with pedal assist. Reaching the upper end means flat pavement, moderate assist levels, correct tire pressure, and a rider of average weight; gradient, headwind, and higher assist settings all move you toward the lower figure. Cooler temperatures temporarily reduce available capacity, which returns as the pack warms.
Tip: Store the pack at 40-80 percent charge in a cool, dry place when the bike will not be ridden for a while, and avoid routinely running it below 10 percent. Both habits measurably extend the usable life of lithium-ion cells.
The supplied charger takes the pack from empty to full in 7-8 hours, which suits overnight charging. The BMS terminates charging automatically once the cells reach full voltage, so the pack can be left connected overnight without risk.
Daily Use & Care
- Check tire pressure before each ride and keep it within the range printed on the tire sidewall.
- Keep the chain clean and lightly lubricated; grit ground into a dry chain wears the drivetrain faster than mileage alone suggests.
- Inspect the mechanical brake pads monthly and take up cable slack at the barrel adjuster as they wear.
- Check that all bolts are torqued to specification after the first week of riding.
- Rinse mud and grit off the frame, rotors, and drivetrain after wet rides, then dry the rotors with a few light brake applications.
- Store the battery at 40-80 percent charge in a cool, dry place whenever the bike will sit unused for more than a few days.
- Book an annual professional tune-up to check wheel true, headset play, and drivetrain wear.
What's in the Box
- 1 x HKM-4196563 city electric bike, largely pre-assembled
- 1 x 36 V 15 Ah lithium battery pack
- 1 x Smart charger
- 1 x Installation tool
- 1 x User manual
- 1 x Rear carry bag
Frequently Asked Questions
How far does it go on a charge?+
Up to 75 mi (120 km) with pedal assist. Rider weight, gradient, assist level, tire pressure, temperature, and wind all affect the number. Flat pavement at moderate assist reaches the upper end.
How long does charging take?+
7-8 hours from empty with the supplied charger. The BMS stops charging automatically at full voltage, so it is safe to leave the pack plugged in overnight.
What riding modes are there?+
Three modes: assist (motor helps your pedalling), ride (minimal help), and pure electric (throttle only, no pedalling). Pick the mode that matches the road and how much exercise you want.
Is it comfortable for commuting?+
A front suspension fork, 26 x 2.35 in balloon tires, and an upright position keep the ride calm over city bumps, and the rear bag carries daily essentials.
How do the mechanical disc brakes compare with rim brakes?+
The rotor sits away from the tire spray zone, so wet performance stays consistent, and it sheds heat better on long descents. Cable actuation is simple to adjust and cheap to maintain.
Can I ride it with the motor off?+
Yes. Switch to ride or pure-electric-off and the bike works as a conventional 7-speed bicycle. It weighs more than a non-electric bike, so a steep climb takes real effort, but the gearing helps considerably.
Service & Policies
Secure Checkout
Every payment is processed through encrypted, PCI-compliant channels. Your financial details are never stored on our servers.
Responsive Support
Our product specialists answer setup, riding, and warranty questions quickly, so you are never left guessing after delivery.
Fast Dispatch
Orders are picked, inspected, and shipped from our warehouse within 0-1 business day, with a tracking number emailed the moment they leave.
Ride-Fit Guidance
Not sure about fit or local e-bike rules? We share rider-height and road-law guidance so you start safely and legally.
Free Shipping on All Orders
Every order ships free. Handling Time: 0-1 business days (Monday to Friday). Transit Time: 2-5 business days (Monday to Friday). A tracking number is emailed as soon as the parcel leaves our warehouse.
180 Days Purchase Protection
Your purchase is protected for 180 days from the delivery date against manufacturing defects and damage in transit. If something arrives wrong, we make it right.
30 Days Money-Back Guarantee
Not completely satisfied? Request a return within 30 days of delivery for a full refund. We keep the process simple and hassle-free.
24 Months Warranty Service
The product is covered by a 24-month warranty from the delivery date against manufacturing defects. Coverage includes parts and labor; normal-wear items are excluded.
250 W Motor36 V 15 Ah540 Wh26 in Balloon TiresShimano 7-SpeedFront SuspensionMechanical DiscCE Certified
Why Choose the HKM-4196563
A Bike That Disappears Into the Commute
Smooth assist, a week of short trips between charges, and a calm balloon-tire ride mean the bike gets out of the way and lets you get on with the day. That is what makes an e-bike worth owning.
Calm Over City Bumps
On potholes, kerbs, and park paths the 26 in balloon tires and front fork keep the ride composed. You feel the road less and enjoy the ride more.
Assist That Follows Your Effort
The pedal-assist system scales the motor contribution to what you are already doing rather than delivering a sudden surge. It feels like strong legs, not like being pushed.
Nothing Inside the Motor to Wear Out
Brushless commutation removes the carbon brushes that wear and heat. The motor runs quietly, stays cooler under load, and needs no internal servicing across the life of the bike.
A Frame That Stays Presentable
An anti-oxidation frame resists corrosion naturally, so winter salt and wet trails do not leave their mark. It also keeps the bike light enough to maneuver in tight spaces.
A Saddle Made for Real Distance
A padded saddle with an upright riding position reduces lower-back and shoulder strain on longer rides, and balanced geometry keeps the bike stable at speed without making low-speed manoeuvring heavy.
Controls & Indicators
Power Button
On the battery pack; hold to switch the system on and off
Assist Buttons
Up and down buttons cycle through the assist modes
Trip Meter
Trip distance and cumulative odometer on the display
Speedometer
Live speed readout in mph, switchable to km/h
Battery Gauge
Remaining capacity indicator driven by the battery management system
Light Switch
Toggle the LED lights from the control pod
Shifter
Indexed shifter for the Shimano 7-speed drivetrain
Pre-Ride Safety Checklist
- Set tire pressure for the ride ahead, within the range marked on the tire sidewall.
- Squeeze both brake levers and confirm the pads bite firmly well before the lever reaches the grip.
- Check the battery is seated, locked, and showing the capacity you expect on the display.
- Spin both wheels to confirm the rims run true and nothing rubs the pads or the frame.
- Check the stem bolts and seat clamp are tight, and rock the bike with the front brake on to feel for play.
- Shift through all 7 gears at low speed to confirm the drivetrain indexes cleanly.
- Select a low assist level for the first minute of riding until you have the feel of the power delivery.
- Wear a helmet, and add gloves and eye protection for longer trips.
Quick Troubleshooting
The motor will not engage.+
Confirm the display is on and showing capacity, the battery is locked in place, and both brake levers are fully released - the cut-off sensors disable the motor while a lever is pulled. Note any diagnostic code shown on the display before contacting support.
Range has dropped compared with when the bike was new.+
Check tire pressure first - a soft tire on tarmac is the single most common cause. Then consider temperature; cool conditions temporarily reduce capacity.
The brakes squeal or feel weak.+
Take up cable slack at the barrel adjuster as the pads wear. Squealing usually indicates contaminated or glazed pads - clean the rotor with brake cleaner and replace the pads in pairs if the noise continues.
The chain skips under hard pedalling.+
Either the drivetrain indexing has drifted or the chain and cassette are worn. Adjust the barrel adjuster a quarter turn at a time. If it skips only in the smallest cogs, replace the cassette together with the chain.
The bike feels vague or wanders at speed.+
Front tire pressure that is too low is the usual cause. Check pressure, then check for headset play by rocking the bike with the front brake applied, and confirm the stem bolts are torqued correctly.
The display shows a diagnostic code and the system will not run.+
Switch the system off, wait 30 seconds, and switch it back on. If the code returns, note the exact code and the conditions that produced it, then contact support.
Certifications & Standards
The HKM-4196563 is CE certified and produced in a facility operating under an ISO 9001 quality management system. The lithium cells and the assembled pack carry the test documentation normally required for lithium-ion transport and sale.
- CE - European Conformity marking for the electrical assembly.
- ISO 9001 - Quality management system certification of the manufacturing facility.
- UN38.3 - Battery transport safety testing, required for lithium-ion shipping by air, sea, and road.
- MSDS - Material Safety Data Sheet available for the battery pack on request.
Important Safety Notes
This bike reaches up to 15.5 mph and weighs around 55 lb before a rider is added, so braking distances are longer than on a conventional bicycle. Read the manual before the first ride, begin on a low assist level, and get a feel for the acceleration and stopping distance in an open area first.
- Wear a helmet on every ride, and add gloves and eye protection for longer trips.
- Do not exceed the 265 lb (120 kg) load capacity, which includes the rider and all cargo.
- Check local law before riding on public roads or paths; a 250 W, 15.5 mph e-bike falls within typical low-speed e-bike classes in many areas, but rules vary.
- Bed the brake pads in with progressive stops from moderate speed during the first rides.
- Do not submerge the bike or use a pressure washer on the motor, battery compartment, or bearings.
- Charge only with the supplied charger, indoors, at room temperature, on a non-flammable surface.
- Do not open, puncture, or modify the battery pack. Damaged lithium cells can vent and ignite.
- Reduce speed on wet surfaces, loose gravel, and descents.
