Place of Origin:Guangdong, China
Brand Name:COSWHEEL
Model Number:T20
Gears:7 Speed
Range per Power:> 60 km
Frame Material:Aluminum alloy
Wheel Size:20"
Max Speed:30-50Km/h
Voltage:48 V
Power Supply:Lithium Battery
Braking System:Hydraulic Disc Brake
Torque:60-70 Nm
Charging Time:>3 hours
Motor position:Rear Hub Motor
Battery Position:Down Tube
Battery Capacity:20 Ah
Product name:Fat Tire Electric Bike
Motor Power:1000W
Warranty:1 Year
Brand Name:COSWHEEL
Model Number:T20
Gears:7 Speed
Range per Power:> 60 km
Frame Material:Aluminum alloy
Wheel Size:20"
Max Speed:30-50Km/h
Voltage:48 V
Power Supply:Lithium Battery
Braking System:Hydraulic Disc Brake
Torque:60-70 Nm
Charging Time:>3 hours
Motor position:Rear Hub Motor
Battery Position:Down Tube
Battery Capacity:20 Ah
Product name:Fat Tire Electric Bike
Motor Power:1000W
Warranty:1 Year
Products Description
Product Paramenters
Brand |
COSWHEEL |
Model |
COSWHEEL T20 |
Key Features |
Original independent and autonomous design ,IP54 waterproof level for the entire e-bike, |
Motor |
500W rated power rear high-speed motor ,1000w peak power |
Shock |
Full front and rear suspension， Hole center 180mm, 1800 pounds, black, 180mm Suspension Travel |
Materials |
Aviation aluminum alloy frame 6061,200000 vibration tests are not easily deformed, far exceeding European standards |
Brake system |
E-ABS front and rear double disc brake system,Power-off brake, line length 1300MM |
Battery |
removbale battery pack equipped battery lock,10Ah/15Ah/20Ah 18650 Li-ion battery optioal |
Torque |
50NM |
Climb Gradient |
About 25° |
Max speed |
45km/h (28mph),Can speed limit 25KM/H |
Meter |
Large 3-inch Color LCD Instrument Display,Cable length 1300mm, SM-5Y, 5 pole cable with USB |
Turn signal |
Tail light with left and right turn signal |
Tire size |
Black off-road Tire 20*4.0 H5176 30TPI with AV+ Liner Belt |
Front fork |
Anti-oxidation 20-inch double-shoulder shock-absorbing front fork |
Headlights |
LED night lighting system with wide angle design |
Charger |
Add defense backflow function, voltage 110V-240V |
Controller |
Maximum load 22A current |
Chain wheel crank |
46T, all aluminum one-piece, sand black crank |
Pedal |
Plastic folding pedal with reflector, axle 9/16 X2 |
Curved handle |
Sand black big swallow handle, φ620*31.8*H:30 |
Seats |
Adjustable seat height，ED iron bow 7.0 clip-free, carry handle section bracket, black leather surface + hollow at the car black leather + tail car black |
Chain |
7-speed rust-proof, S33GY*128L |
Gearbox |
Shimano 7-speed drivetrain |
Foot brace |
20" mountain bike aluminum adjustable side bracket + black plastic adjustment legs + all black crystal label |
fenders |
Front and rear fenders are wrapped inside support, front fender with two support sticks |
Max load |
150kg |
Mileage |
60-150km |
Size |
Dimension 180*65*115cm，Packing Size 138.5*30*78cm |
Details Images
Product packaging
Specification
1.Coswheel T20 e-bike
2.Side reflector
3.Front wheel quick release
4.Front and rear fender screws
5.Hex tool screwdriver
6.Pedal
7.Charger
8.Manual
