Electric Bicycles >>
HKM-1096275 31 mph Mid-Drive Electric Bicycle, 48V 15Ah 720Wh Down-Tube Battery, 9-Speed Shimano Drivetrain, 27.5 x 2.4 in Tires
HKM-1096275
31 mph Mid-Drive Electric Bicycle
The HKM-1096275 is a mid-drive trekking bike rather than a hub-motor commuter, and the difference shows on hills. The motor sits at the bottom bracket and drives the chain, so every gear you select multiplies motor torque as well as your own.
Key Features
8 details that make the HKM-1096275 a dependable ride.
mid-drive Brushless Mid-Drive Motor
A mid-drive brushless mid-drive motor drives the HKM-1096275. There is no gearbox or second chain between the motor and the road, so drive losses stay low and routine maintenance comes down to keeping the axle hardware torqued and the drivetrain clean.
48 V 15 Ah Lithium Pack (720 Wh)
The 48 V 15 Ah pack stores 720 Wh of usable energy, which is what makes the quoted 37-50 mi (60-80 km) window realistic rather than optimistic. Charging from empty takes just over 3 hours on the supplied charger, and partial top-ups take proportionally less - there is no need to run the pack down before plugging in. A battery management board supervises cell balance, over-charge, over-discharge, and temperature so the pack is protected during both fast riding and long storage.
Suspension Fork and A Rigid Rear End
The fork takes the edge off gravel, root, and broken tarmac while the rigid rear triangle keeps pedalling losses low and gives the mid-drive a solid platform to push against. For a bike that spends most of its life on tarmac and hardpack, that split does more for average speed than full suspension would.
Hydraulic Disc Brakes
Sealed hydraulic lines actuate both calipers, so lever effort stays light and predictable when the rotors heat up on a long descent and there are no cables to stretch or corrode. Motor cut-off switches in both levers kill drive the instant either lever moves, which matters on a machine that reaches 31 mph.
Mid-Drive Motor Working Through 9 Shimano Speeds
Because the motor drives the crank rather than the wheel, it uses the same 9-speed Shimano gear range you do. Drop two gears at the bottom of a climb and the motor spins up into its efficient band instead of lugging, which is why 60-70 N.m at the crank pulls harder up a steep pitch than a larger hub motor with the same rating. Weight also sits low and central, so the bike steers like a bicycle rather than a rear-heavy scooter.
27.5 x 2.4 in Tires for Road and Hardpack
At 2.4 in the casing is wide enough to run lower pressure on gravel and forest road without pinch-flatting, but the tread stays low enough to roll quietly and efficiently on tarmac. The larger 27.5 in diameter rolls over square edges that stop a 20 in wheel.
Backlit LCD with Cadence Readout
Speed, charge, assist level, trip distance, and odometer are laid out on a backlit LCD that stays legible in direct sun. A cadence readout is genuinely useful on a mid-drive: holding 70-85 rpm keeps the motor in its efficient range and is the single easiest way to add miles to a charge.
Down-Tube Battery and A 3 Hour Charge
The 48 V 15 Ah pack sits in the down tube behind a lockable cover, low and between the wheels, which is the ideal place on a bicycle for 8 lb of mass. A 4 A charger refills it in just over three hours, so a bike used for a lunchtime errand can be back at full charge before the commute home.
Overview
Built for the ride ahead.
The HKM-1096275 is a mid-drive trekking bike rather than a hub-motor commuter, and the difference shows on hills. The motor sits at the bottom bracket and drives the chain, so every gear you select multiplies motor torque as well as your own. Drop to the largest sprocket at the foot of a climb and the bike walks up it at a cadence you can sustain. A 48 V 15 Ah pack in the down tube stores 720 Wh and keeps the mass low and central. Combined with the crank-mounted motor, the weight distribution is close to that of a loaded touring bicycle, which is why the bike still feels neutral turning into a corner or braking hard on a descent. The 9-speed Shimano drivetrain covers everything from a steep loose pitch to a fast descent, and the hydraulic disc brakes are sized for the 31 mph the bike is documented for.
Planted, Durable Steel Frame
A steel frame gives the HKM-1096275 a planted, durable feel under load.
Engineered to be the thing you stop thinking about, because it simply works. Good gear should ask for nothing and give back everything; that is the bar here.
Full Specifications
Measurements are shown in US customary units first, with metric equivalents in parentheses.
Battery, Range, and Charging
Up to 37-50 mi (60-80 km) per charge.
The 48 V 15 Ah pack holds 720 Wh. Most mainstream commuter e-bikes ship with 400-600 Wh, so this pack sits well above that band, and the extra energy is what turns a nervous end-of-day commute into an ordinary one. Real-world range moves with four things more than anything else: how much you pedal, total rider and cargo weight, tire pressure, and terrain. Throttle-heavy riding at the top of the speed range sits at the low end of the 37-50 mi (60-80 km) window. Moderate assist on rolling terrain lands in the middle. Light assist on level ground with a steady cadence is what produces the high figure. Cold weather below 40 F (4 C) temporarily trims available capacity by 10-20 percent; the capacity comes back once the pack warms up again.
Daily Use & Care
A short routine keeps the ride quiet and the range where it should be.
Tire pressure sets the character of the ride. Run the upper half of the sidewall pressure range on pavement for lower rolling resistance, and drop toward the lower half on gravel or dirt so the casing can flatten and grip.
Rinse the frame, rims, and drivetrain with fresh water after riding on salted roads or wet gravel. Road film attacks aluminum and steel fasteners over time if it is left in place.
Check the axle hardware and stem bolts before the first ride of each week. Motor torque works fasteners loose faster than on a conventional bicycle.
Wipe and re-lubricate the chain every 100-150 mi, or after any ride through standing water or heavy dust. A dry chain wears the Shimano cassette far faster than a clean, oiled one.
Inspect brake pad thickness monthly. Pads wear silently until they are gone; replace the friction material once it is under 1 mm.
Charge indoors at room temperature and unplug once the charger indicator turns green rather than leaving it connected for days at a time.
Keep the display boot and the charge-port cover closed when the bike is parked outside so moisture stays out of the connectors.
Torque the 27.5 in spoke nipples and check wheel true after the first 50 mi. New wheels bed in, and a 62 lb machine loads the spokes harder than a conventional bicycle does.
What’s in the Box
Everything needed to get riding, right out of the box.
1 x HKM-1096275 Bike
1 x HKM-1096275 bike
1 x 48 V 15 Ah Lithium Battery Pack
1 x 48 V 15 Ah lithium battery pack
1 x 4 A Smart Charger with 100-240 V Input
1 x 4 A smart charger with 100-240 V input
2 x Battery or Lock Keys
2 x Battery or lock keys
1 x Pair of Pedals
1 x Pair of pedals
1 x Toolkit with Hex Wrenches and Pedal Spanner
1 x Toolkit with hex wrenches and pedal spanner
1 x User Manual and Assembly Guide
1 x User manual and assembly guide
Why Choose the HKM-1096275
6 reasons it earns its place.
Torque Where A Bicycle Wants It
A mid-drive puts its 60-70 N.m through the chain and the cassette, so gearing multiplies it exactly the way it multiplies your legs. The practical result is that steep, slow climbs - where hub motors overheat and bog - are the terrain this layout handles well.
Trekking Geometry
Long-distance trekking geometry, a suspension fork, and 2.4 in tires make canal paths, forest roads, and rough municipal tarmac all viable on the same bike, without the rolling penalty that comes with a fat tire.
Two Ways to Ride
Twist the throttle for immediate, clutch-free acceleration, or shift through the 9-speed Shimano drivetrain and pedal. Most owners mix both: throttle to pull away from a stop, gears and pedal-assist to stretch the range on the flat, and full power for the hills.
Quiet Under Power
The motor sits at the crank and drives the existing chain, so it uses the Shimano gear range instead of fighting it. Fewer separate drive components means less to service, and the centred mass keeps the handling neutral.
A Practical Alternative to A Second Car
A full 720 Wh charge costs a few cents of household electricity and covers 37-50 mi (60-80 km). There is no fuel, no oil change, and no emissions test. For trips under 10 mi the bike is usually quicker door to door than a car once parking is counted, and it removes a daily short-trip journey from the vehicle that costs the most to run.
Balanced Mass
Motor at the bottom bracket, battery in the down tube: the two heaviest components sit low and near the middle of the wheelbase. The bike changes direction and brakes like a bicycle, which is not something you can say about every e-bike with a large rear hub.
Shock Absorption That Takes the Edge Off
Shock absorption on the HKM-1096275 takes the edge off curbs and seams.
The finish is the kind you notice with your hands before your eyes. Built for the life actually being lived, not the one staged for a photo. The HKM-1096275 pairs a Brushless mid-drive motor at the bottom bracket, 60-70 N.m rated torque, 48 V 15 Ah lithium-ion (720 Wh), removable and lockable, a range of 37-50 mi (60-80 km), varies with terrain, rider weight, tire pressure, and assist level, so it is built for real-world rides rather than showroom specs.
Controls & Indicators
What each control on the HKM-1096275 does.
Power Button
Located on the battery pack; hold to switch the system on and off
Assist Level Buttons
Up and down buttons on the display cycle through the pedal-assist levels plus zero assist
Throttle
Right-hand twist grip; proportional response, works independently of the assist level
Speedometer
Live speed readout in mph, switchable to km/h in the display settings menu
Battery Gauge
Segmented state-of-charge indicator plus voltage or percentage readout on the display
Light Switch
Long-press the up button to toggle the LED headlight and tail-light
Shifter
Right-hand index shifter for the 9-speed Shimano rear derailleur
Frequently Asked Questions
Quick answers about the HKM-1096275.
How much assembly is required out of the box?
The bike ships approximately 85 percent assembled. What remains is fitting the front wheel, straightening and bolting the handlebar, installing the pedals and saddle, and checking brake alignment and rotor clearance. Budget 30-45 minutes with the supplied tools, and have a shop check torque and bed the brakes in if you are not comfortable doing that yourself.
What range should I actually plan for?
Plan for 37-50 mi (60-80 km). Headwinds, hills, cold weather, heavier riders, and low tire pressure all pull the figure down; a warm day, firm tires, and a steady pedaling cadence push it back up.
How long does the battery take to charge?
About just over 3 hours with the supplied charger from a fully empty pack. Partial top-ups take proportionally less time, and the pack does not need to be run down before recharging. Charging with the pack on board works exactly as well as charging it on a bench.
Is there a throttle on this bike?
No. It is a pedal-assist bicycle - the mid-drive adds power in proportion to your assist setting when you turn the cranks. That is also what keeps it inside Class 1 and Class 3 style rules in most places, subject to the local speed limit for assisted riding.
Why does a mid-drive need more chain maintenance?
Motor torque and rider torque both pass through the same chain and cassette, so the drivetrain sees more load than on an unpowered bicycle. Clean and lubricate the chain every 100-150 mi, shift under reduced power, and expect to replace chains more often than cassettes.
Is a license or registration required?
Rules vary by state and by city. The common three-class US e-bike framework caps assisted speed at 20 or 28 mph and motor output at 750 W, and this machine is documented at 31 mph with a mid-drive rating, so it may fall outside class limits where you live and be treated as a moped or motor-driven cycle. Check your state DMV and local ordinances before riding on public roads or shared paths.
Can I ride it with the motor switched off?
Yes. The 9-speed Shimano drivetrain works independently of the motor. At roughly 62 lb the machine is heavy for unassisted pedaling, so getting home on a flat pack is slow but entirely possible on level ground.
Is the battery removable for indoor charging?
Yes. It unlocks with the supplied key and lifts out for charging at a desk while the bike stays locked outside. You can also charge it in place through the frame-side port.
Quick Troubleshooting
Common issues and what to check first.
The motor does not engage when I twist the throttle.
Confirm the display is on and showing charge, the battery is locked into place, and both brake levers are fully released - the brake cut-off sensors disable drive while a lever is pulled. If the display shows an error code, note the code and contact support.
Range dropped noticeably compared with when it was new.
Check tire pressure first; a soft tire on pavement is the most common cause. Then consider temperature, because cold reduces available capacity temporarily. If range is down more than 30 percent year-round after many charge cycles, the pack is approaching the end of its service life.
The brakes feel spongy or the lever pulls to the grip.
Sponginess in a hydraulic system normally means air in the line or a fluid leak. Stop riding and have the system bled and inspected - do not continue on a 31 mph machine with compromised brakes.
The chain skips under hard pedaling.
The Shimano indexing is out of adjustment or the chain and cassette are worn. Turn the barrel adjuster a quarter turn at a time to realign the indexing. If the chain skips only in the smallest cogs, the cassette is worn and should be replaced together with the chain.
There is a rattle or knock from the suspension over bumps.
Check that the axle and any quick-release lever are fully closed and that the wheel is seated in the dropouts. If the noise persists, inspect the stanchions or shock body for scoring and have a shop service the unit.
The display shows an error code and the machine will not move.
Switch the system off, wait 30 seconds, and switch it back on. If the code returns, note the exact code and the conditions that produced it, then contact support - error codes map to specific faults in the controller, motor, throttle, or battery circuits.
Certifications & Standards
Documented and tested for sale.
CE
European Conformity (CE) marking where applicable for the safety and electrical assembly.
ISO 9001
Quality management system held by the manufacturing facility.
Compliance Docs
Safety and compliance documentation included with every unit on request.
Tested
Each unit is inspected and function-tested before it leaves the warehouse.
From Frame to Wheels
From the frame to the wheels, the HKM-1096275 is built for consistent, confident performance.
The specifications above show exactly what is under the surface, and the ride proves it every time. The HKM-1096275 pairs a Brushless mid-drive motor at the bottom bracket, 60-70 N.m rated torque, 48 V 15 Ah lithium-ion (720 Wh), removable and lockable, a range of 37-50 mi (60-80 km), varies with terrain, rider weight, tire pressure, and assist level, so it is built for real-world rides rather than showroom specs.
Pre-Ride Safety Checklist
Run through these before every ride.
Check tire pressure and set it for the surface you plan to ride; pressure has more effect on range and grip than any other single adjustment you can make in 30 seconds.
Squeeze both brake levers. They should firm up well before touching the grip, with no sponginess or long lever travel.
Confirm the battery is seated and locked and that the display shows the state of charge you expect.
Spin both wheels and check that the rims run true and that nothing rubs a brake pad or the frame.
Check that the axle hardware is tight and that the headset has no play when you rock the machine with the front brake applied.
Test the throttle at walking pace in a clear, traffic-free area before riding in traffic.
Switch on the headlight and tail-light if you will be riding near dusk, and wear a helmet rated for the speed this machine reaches.
Confirm that the display reads the assist level you expect before you set off, so the first throttle input is not a surprise.
Service & Policies
Every HKM-1096275 is backed by coverage designed to protect your investment.
Free Shipping on All Orders
Every order ships free. Handling Time: 0-1 business days (Monday to Friday). Transit Time: 2-5 business days (Monday to Friday). A tracking number is emailed as soon as the parcel leaves our warehouse.
180 Days Purchase Protection
Your purchase is protected for 180 days from the delivery date against manufacturing defects and damage in transit. If something arrives wrong, we make it right.
30 Days Money-Back Guarantee
Not completely satisfied? Request a return within 30 days of delivery for a full refund. We keep the process simple and hassle-free.
24 Months Warranty Service
The product is covered by a 24-month warranty from the delivery date against manufacturing defects. Coverage includes parts and labor; normal-wear items are excluded.
Important Safety Notes
Read before the first ride.
This bike is rated at 31 mph. Read the manual first and practise throttle and braking in an open, traffic-free area. Leave extra room for braking, since stopping distance grows fast with speed and load. Wear a helmet every ride; a certified downhill or motorcycle helmet is wise at 31 mph. Do not exceed the 265 lb (120 kg) load limit, including rider, cargo, and rack load. Confirm local law before riding on public roads. Bed the brakes in with 10-15 progressive stops over the first rides. Never ride through water deep enough to reach the motor or battery. Charge only with the supplied charger, indoors and attended. Never open, puncture, or modify the pack. Slow down substantially on gravel, wet surfaces, and steep descents.
HKM-1096275 - mph Mid-Drive Electric Bicycle. Specifications are for reference; actual performance varies with rider, terrain, tire pressure, and temperature. This page describes the product only and is not legal advice regarding vehicle classification - confirm local regulations before riding on public roads.
