HKM-378707 Mini ZVS Induction Heating Power Module 12-24V DC 120W for Tesla Jacobs Ladder
Introducing the HKM-378707 Mini ZVS Induction Heating Power Module, a remarkable solution for your induction heating needs. Designed to operate efficiently within an input voltage range of 12-24V DC, this module delivers an impressive output power of 120W, making it an ideal choice for applications such as driving a Tesla Jacobs Ladder without needing a cooling fan.
This Mini ZVS power module stands out with its compact dimensions of 55mm in length, 37mm in width, and 1.6mm in thickness, making it easy to integrate into your existing projects. It features a tapless design that enhances its reliability during operation. Please note that when operating at 12V, the module can achieve significant heating performance, though the configuration of the primary coil, typically at 10 turns, will yield around 30W output.
A key aspect of using the HKM-378707 effectively is ensuring that all components are properly soldered and that the power connections are positive and negative without any reversals. When working with loads such as heating coils or high-voltage packages, it’s crucial to power up only after these connections are confirmed. Be aware that powering on without a load may result in damage to the module.
To optimize the heating process, keep in mind the recommended dimensions for your heated objects. Ideally, the width should be between 1/3 to 1/2 of the inner diameter of the heating coil, and the diameter should be limited to within 20mm for optimal results. This is particularly important to achieve effective heating without overstressing the module.
Included with your HKM-378707 Mini ZVS Induction Heating Power Module is one meticulously crafted metal power module, ready to enhance your induction heating projects. Experience the powerful capabilities of this innovative module and unlock a new level of efficiency in your heating applications.
Product information:
Model: Mini ZVS
Type: Module power supply
Input voltage: 12-24 (V)
Output power: 120 (W）
Feature:
Mini ZVS tapless finished product induction heating Tesla Jacobs ladder drive without cooling fan
High power 120W (when 12V induction heating). When the high voltage package is 12V and the primary is 10 turns, it is about 30W.
The input voltage is DC 5V~12V, this voltage range is the voltage when working, not the voltage when the power supply is no-load!
Confirm that all components are welded correctly, and the positive and negative power cords are not reversed. After connecting the load (heating coil, high-voltage package), re-energize! No power on without load! No-load power on is easy to damage!
PCB board size: length * width * thickness 55mm*37mm*1.6mm
The width of the heated object should be as far as possible between 1/3~1/2 of the inner diameter of the heating coil, and should not exceed 2/3!
The diameter of the heated object should be controlled within 20mm as far as possible. If it is too large, it will be more difficult to heat to redness. After all, the power is limited.
Packing list:
Metal power module*1
